VT-TABLET-5081
14/ 18
3.7 Interface Description
3.7.1 Internal MIC in Interface
This hole is used to the onboard MIC in.
3.7.2 USB OTG (USB type C)
It is a USB2.0 OTG port (USB type C), you can connect to PC as USB
client to manage the android device and connect a USB device using USB OTG
to HOST adapter cable. It also can connect to USB adapter charge the table.
3.7.3 3.5mm Headphone Jack with external MIC in
It is a standard 4-pole 3.5mm Headphone Jack with external MIC in ,
every pole signal is defined as below.
3.7.4 WPC
The tablet with a standard WPC1.1 passivity receiving terminal. We can
charge the table with WPC ant.
3.8 Packing List
