2. Camera Overview
NO. Name Description
1
2
3
4
Mount Connector
Speaker
Front Camera Lens
Power Button
Connects to the Suction Cup Mount.
Delivers sound during video playback.
Front Facing Camera for video
recording road events.
Power ON/OFF; IR LED Light Switch.
5
6
7
8
Up Button
Down Button
Menu Button
Microphone
Move selector up; rewind; Microphone
on/off.
Move selector down; fast forward;
Turn off LCD screen.
Enter/exit setup menu.
Records clear audio with the video
footage.
9
10
11
Snapshot / Emergency /
Parking Mode Button
OK Button
LCD Screen
Snapshot: Manually locks the currently
recording video clip following emergency
or to preserve important videos; Long
press to enter Parking Mode.
Confirms the action; Stop/Start the
video recording.
1.5” TFT Color LCD Display.
1 2 3
48
9 10 11 13
12
15
16
17
5 6 7
- 2 -
