1.Patns List
CODE PART QTY
HOOD&BODY
A1 Hood (Pre-Assembled to Body) 1
A2 Burner 4
A3 Cooking grid 1
A4 Warming rack 1
A5 Grease cup 1
A6
Drip tray
1
A7 Side burner valve/Hose Assembly 1
A8 Flame Tamer 2
A9
iron plate
1
SIDE
SHELF
B1 side shelf 1
B2 Knob 5
B3 Side shelf Knob bezel 1
B4 Side burner 1
B5 side burner shelf 1
B6 Side burner grid 1
B7 Hook 1
TROLLEY
C1 Right side trolley Assembly 1
C2 Side panel 2
C3
Door (R)
1
C4
Lock castor
2
C5
Trolley Base
1
C6
magnet
1
C7
Door handle
2
C8
castor
2
C9
Door (L)
1
C10
Left side trolley Assembly
1
C11
Upper rim
1
C12 Rear panel 1
C13 Lighting Rod Assembly 1
HARDWARE
D1
M6×12 bolt & Ø6 spring washer
15
D2 Door axe 2
D3 Ø6 washer 4
D4 M3×15 bolt 2
D5 M4×8 bolt & Ø4 spring washer 8
D6 M5×12 bolt & Ø5 spring washer 14
