Thank you for choosing Vaporesso product. Please read this instruction carefully before
use to ensure a perfect experience.
If there is any additional requirement about this product, please consult the local agent
or contact us through our website: www.vaporesso.com
Drip Tip
Front Front
ARMOUR MAX ARMOUR S
Back Back
Top Cap Button
Glass Tube
Tank Protective Cover
Air-Inlet Port
Power & Lock Button
Base
0.96" TFT Screen
“Up” Button
Battery Door
“Down” Button
Type-C USB Port
Battery Door Button
Dimensions: 157*56.5*34mm
POD Capacity: 8ml/2ml(TPD)
Coils & Suggested Wattage:
GTi 0.2Ω MESH Coil (60-75W)
GTi 0.4Ω MESH Coil (50-60W)
Battery Capacity: 2 x 21700 or 2 x 18650
Output Power: 5-220W
Charging Current: DC 5V/2A, Type-C
Battery Display: 0.96’’ TFT Screen
Dimensions: 154.8*41.9*36mm
POD Capacity: 5ml/2ml(TPD)
Coils & Suggested Wattage:
GTi 0.2Ω MESH Coil (60-75W)
GTi 0.4Ω MESH Coil (50-60W)
Battery Capacity: 1 x 21700 or 1 x 18650
Output Power: 5-100W
Charging Current: DC 5V/2A, Type-C
Battery Display: 0.96’’ TFT Screen
EXPLOADED VIEW
SPECIFICATION
FIGURE
Figure 1: Replace the coil
PUSH
Figure 2: Fill e-liquid
Figure 3: Remove Tank Protective Cover
1 x VAPORESSO ARMOUR MAX MOD
1 x VAPORESSO iTANK 2 (8ml/2ml TPD)
1 x GTi 0.2Ω MESH Coil (Pre-installed)
1 x GTi 0.4Ω MESH Coil (In-box)
1 x Extra Glass Tube
1 x Tank Protective Cover(Pre-installed)
2 x O-ring
1 x Refilling Silicone Plug
2 x 18650 Sleeve (Inside the MOD)
1 x Type-C Cable
1 x User Manual & Warranty Card
1 x Safety Manual
1 x Reminder Card
1 x VAPORESSO ARMOUR S MOD
1 x VAPORESSO iTANK 2 (5ml/2ml TPD)
1 x GTi 0.2Ω MESH Coil (Pre-installed)
1 x GTi 0.4Ω MESH Coil (In-box)
1 x Extra Glass Tube
1 x Tank Protective Cover(Pre-installed)
2 x O-ring
1 x Refilling Silicone Plug
1 x 18650 Sleeve (Inside the MOD)
1 x Type-C Cable
1 x User Manual & Warranty Card
1 x Safety Manual
1 x Reminder Card
PACKING LIST
ARMOUR MAX ARMOUR S
PULL OUT
PULL IN
Figure 4: User Interface
Wattage
Smart
Function
On/Off
Lock On/Off
Resistance
Left Battery Power
Puff/Time Counter
Right Battery Power
Mode
CLOSE
INJECTION
To Next Page
