Varimixer W30 - Single Speed Transmission

20
SINGLE SPEED TRANSMISSION
PART NUMBER
W40PI
W60PI
DESCRIPTION
FIG.
NO.
0
1.
2.
3.
4.
5.
6.
7.
8.
9.
10.
11.
12.
13.
14.
15.
16.
17.
18.
Motor Pulley
Screw
Motor Plate
N/A
Belts
Center Pulley
Snap Ring
Pedestal Shaft
Key
Pulley
Snap Ring
Bearing
Snap Ring
Washer
Distance Tube
Arm for Bearing
Bolt
Assembly (Items 6-11)
33V315
STA 5018
60-61
N/A
3VX400
33V80
STA 3410
15-41
STA 2022
27-128
STA 3410
27-102
STA 3514
STA 6010
15-143
30-6
STA 5348
40S-6M
33V315
STA 5018
60-61
N/A
3VX425
33V80
STA 3410
60-41
STA 2022
60-128
STA 3410
27-102
STA 3514
STA 6010
15-143
30-6
STA 5348
40S-6M
