Varioprop Uno S2R - Transmitter Nomenclature; Component Identification

To Next Page

To Previous Page

ON/OFF Switch

LED Indicator

BIND Button

Steering Reverse

5:5 / 7:3 ThrottleSwitch

Steering Trim

Throttle Trim

Adjusts the throttle in small increments

so the model will not move at neutral.

Adjusts the steering in small increments

so the model will run straight.

Antenna (Built-in)

Steering

Dual Rate (D/R)

Steering Wheel

Throttle Trigger

Battery Tray

Throttle Reverse

Turn model to left or right.

Control the speed of the model and

movement forward and backward.

Adjust the steering

sensitivity across the

entire range.

It blinks at Low Battery.

Adjust the proportion of throttle signal

To link to the receiver.

Reversing Switch.

Battery location.

WARNING : Do not cover/hold the built-in antenna part of the transmitter by your hand during

running. Do not put any conductive plate/sticker on the antenna part. Otherwise, the

operating range may become shorter.

NOMENCLATURE
