General information
3
VÄRMEBARONEN EP 31 300
Notes
Serial number Date of installation
Plumber
Tel
Electrician
Tel
Other,
Filled in when the boiler is installed!
External temperature setpoint
 no  0-10 V  0-5 V  4-20 mA
External stage limit
 no  0-10 V  0-5 V  4-20 mA
Max. limit
°C
Min. limit
°C
Settings
Installed power
kW
Number of stages
Load guard
 yes  no
Main fuse
A
Primary transformer
(xxxx/5)
Current limit
A
Margin
A
7 stage, EP
 31  42  52  63  70  84  98  119
Art.no.
5601 5602 5603 5604 5605 5606 5607 5608
15 stage, EP
 67  90  99  112  135  150  180  225  255  270  300
Art.no.
5609 5610 5611 5612 5613 5614 5615 5616 5617 5618 5619
UTK - heating curve
P1
T
outside
= 20°C °C
P7
T
outside
= -10°C °C
P2
T
outside
= 15°C °C
P8
T
outside
= -15°C °C
P3
T
outside
= 10°C °C
P9
T
outside
= -20°C °C
P4
T
outside
= 5°C °C
P10
T
outside
= -25°C °C
P5
T
outside
= ±0°C °C
P11
T
outside
= -30°C °C
P6
T
outside
= -5°C °C
Temperature adjustment
°C
