Place the front wheel into the forks, make sure the fork hangers are
secured to the axle and make sure the disc is placed in the middle of
the brake, tighten the flange nuts on both sides using a No.7 (M15
wrench) tool.
(4) Installation Of Fenders And Lights
1.Suitable For C20-1/C26-2/C20-1 Pro Model
Loosen the screws in the corresponding positions of the front wheels as
shown below. Place the fender in this position.
Attach the headlights and refasten the loose screws. Adjust the position of the
lights and tighten the screws.
