Model #: XL-1
Please call for replacement parts or assistance: 1-866-942-5362
VAS Furniture Mfg. Inc. Factory No. 55-12029 Page 11
Assembly Instructions
12. You can install your Plasma / LCD TV directly, using the appropriate Bolts through the
Lock Washers and Flat Washers through the proper holes of Mounting Plate pre-
attached on the Deluxe Bracket (I) and then into the back of the TV set. See detail #7.
Note: Hand threading the bolt in the TV Mounting Kit included into the threaded insert
on the back of the TV to determine correct size bolt you will require. If you are unable to
find the correct one, consult a local hardware store.
Parts Required Tools Required
See TV Mounting Kit Phillips Screwdriver
