88 Climate control
Climate control
Climate control systems ............... 88
Air vents ....................................... 91
Maintenance ................................ 92
Climate control systems
Heating and ventilation
system
Controls for:
■ Temperature
■ Fan speed
■ Air distribution
Heated rear window Ü 3 30.
Temperature
red = warm
blue = cold
Heating will not be fully effective until
the engine has reached normal
operating temperature.
Fan speed
Adjust the air flow by switching the fan
to the desired speed.
Air distribution
M
= to head area
L
= to head area and foot well
K
= to foot well
J
= to windscreen, front door
windows and foot well
V
= to windscreen and front door
windows
Intermediate settings are possible.
Demisting and defrosting the
windows
■ Set temperature control to warmest
level.
■ Set fan speed to highest level.
■
Set air distribution control to V.
■
Switch on heated rear window Ü.
