www.vax.co.uk
4
preparing the cleaner
3. Preparing the Cleaner
Raising the Handle
Your cleaner is fully assembled and ready to start cleaning.
Raise upper handle (A) to upright position until it locks in
place (Fig.3/1).
To fold handle for storage, press upper handle release
button and fold handle back.
Filling the Solution Tank
IMPORTANT: Unplug deep cleaner from electrical
socket before filling or emptying tanks.
Press solution tank release button and remove solution
tank (Fig.3/2)
R
elease la
tches on tank cap and remove (Fig.3/3).
Use cap to measure the correct amount of solution
according to the instructions on the bottle (Fig.3/4).
Pour solution into tank. Fill tank to fill line with warm tap
water (max 50°C) (Fig.3/5).
Replace cap and secure both latches. Place bottom of tank
onto cleaner. Pivot top of tank and snap in place (Fig.3/6).
Fig.3/1
Fig.3/2
Fig.3/3
Fig.3/4
Fig.3/5
