GETTING STARTED
ATTACHING THE WALL MOUNT
Without the handheld attached to the
reach wand and powered head, push the
wall bracket onto the top and back of the
reach wand.
Choose a location for the machine to be stored, preferably near to a mains supply
although not directly above or below a mains socket. Stand the machine powered
head and wand against the wall, ensuring the powered head is at on the oor.
Holding the wall bracket securely against
the wall, make a small mark for each
screw. Secure the wall bracket to the
wall using the wall plugs and screws.
The dusting brush can be tted onto the
wall bracket.
Fully assemble the machine and rmly
press the machine into the wall bracket
to secure. Always ensure the machine is
securely locked into place.
ASSEMBLY
To assemble the dirt container, line up the arrow on the dirt
container connection with the arrow on the handle. Push the
dirt container onto the handle until it clicks into place.
Attach the handheld to the reach wand until it clicks into place.
Attach the reach wand to the powered head until it clicks into
place. Push the tool caddy onto the reach wand and slot the
crevice tool into place.
