3. How to Assemble

Use a crosshead screwdriver

Components

Assembly

Line up mid-section with base unit and slot into place (Fig

3/6).

Insert handle into mid-section ensuring that the solution

trigger is at the back of the machine and the screw hole

in the handle is lined up with the screw hole in the mid-

section (Fig 3/7).

Insert and tighten (Fig 3/8).

Fig.3/5 - Clean Water Tank

Fig.3/6

Fig.3/7

Fig.3/4 - 3 Screws

Fig.3/3 - Handle

Fig.3/2 - Mid-Section

Fig.3/1 - Base Unit

Align screw holes
