Vax PowerMax VRS6W

---
Machine Overview
Unit
Accessories
2
1
Handle
2
Clean water tank carry handle
3 Clean water tank release lever
4 Clean water tank
5
Dirty water tank release lever
6 Dirty water tank carry handle
7 Dirty water tank
8
Brushbar
(hidden)
9
Pre-motor filter
(
hidden)
10 Water/solution mix trigger
11 Cord storage hook
12 Upper cord storage
13 Power cord
14 Carry handle
15 Lower cord wrap clips
16 On/off button
17 Recline pedal
18 Vax carpet cleaning solution
19 Float chamber filter
(
hidden)
