Vax Rapide Ultimate W87-RH-P User Manual

Machine Overview
Handle
Solution trigger (hidden)
Clean water tank release button
Clean water tank
Recline pedal
Solution tube port
Dirty water tank release lever
Dirty water tank carry handle
Hose port
Rotating brushbar (hidden)
On/o pedal
Power cord release lock
Power cord (hidden)
Hose
Wash tool
Wash tool solution trigger
Handle locking pin (hidden)
Vax pre-treatment carpet
cleaning solution
Pre-treatment wand
Pre-treatment wand holder
Vax carpet cleaning solution
Float chamber lter
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
NOTE: Some parts may vary according to model. Please check inside ap of box for more details.
2
9
5
8
4
3
10
17
6
7
12
11
16
15
14
18
13
2vax.co.uk
22
20
19
21
1
19
