Let’s talk technical
Replacing the belt
Place belt on rounded
area of brushbar
without bristles.
Line up right side of
brushbar with base, push
into place. Lift and push
left side of brushbar until
clicks into place.
Lie vacuum cleaner
on its back exposing
brushbars. Use a cross
head screwdriver.
Undo 5 screws.
Line up brushbar
cover, push until it
clicks into place.
Replace 5 screws
and tighten.
Lift to remove
brushbar cover.
Lift to remove
brushbar. Remove and
dispose of old belt.
Clean any debris from
spindle. Place new
belt on spindle.
Remove hose end
from the oorhead.
Lift clip under the
hose inlet.
Pull latch out and
remove hose.
Line up latch, push until
it clicks into place.
Removing a blockage from the hose
Accessories
If the brushbar does not
rotate easily then the belt
may not have been tted
correctly. Make sure the
belt is not twisted.
CAUTION
Remove any blockage by inserting
a long, blunt object in to the hose.
TIP
Test for blockages by
dropping a small ball of
paper through the those.
Remove any blockage
by inserting wire
