Machine Overview
Unit
2
Vax Careline
0844 412 8455
2
4
1
5
6
7
12
13
Filters
16 Central HEPA filter
Accessories
17 Pre motor filter 18 Crevice tool
3
19 2-in-1 tool
20 TurboTool (some machines only)
9
8
10
1 Handle
2 TurboTool
(some models only)
3 Dirt bin release button
4 Carry handle
5
Central HEPA filter
6 Dirt bin
7 Carpet height adjust
8
Hose to machine connector
9 Extension wand
10 Crevice tool
11 2-in-1 tool
12 Hose
13 Release pedal
14 On/off pedal
15 Carry handle
