VBX Wellness 3500 - Machine Diagram

1. Control Panel
2. Panel Permanent Seat
3. Screw [M6x12]
4. Handrail
5. Screw [M6x16]
6. Extension Tube
7. Lock Catch
8. Support Tube
9. Plastic Bolt [M8]
10. Base
11. Base Feet
of 4 10
MACHINE DIAGRAM
1
2
3
4
5
6
7
8
9
10
11
