VDH MC 785 KLIMA User Manual

User manual Document Nr. : 080631 Version : V1.0
MC 785 KLIMA 0-100C Client : General Page : 3 of 16
1. Technical specifications
General
Type : MC 785 KLIMA
Wall mount version:
Housing : Grey plastic
Material : Polystyrol 454h KG 2 natur BASF
Dimensions : 213 x 180 x 85mm (whd)
Front : Polycarbonate (IP-44)
Panel mount version:
Housing : Steel case for panel mount
Material : Steel silver grey painted
Dimensions : 217 x 155 x 85mm (whd)
Panel cut : min. 208 x 146mm (wh)
Front : Polycarbonate (IP-44)
Temperature range : 0/+100C per 0,1C
Rel. humidity range : 0/+100% RH per 0,1% RH
Power supply : 230 Vac; 50/60 Hz (-10/+5%).
Power consumption : 9 VA
Operating temperature : -20/+50C
Operating rel. humidity : 10/+90 % RH not condensing
Accuracy : ± 0,5 % of the range
Front
Display : 4-digit digital display for measured temperature
4-digit digital display for temperature set point
4-digit digital display for measured RH
4-digit digital display for RH set point
LED's : COOL = LED Relay cooling active
HEAT = LED Relay heating active
DEHUM = LED Relay dehumidifying active
HUM = LED Relay humidifying active
= LED Alarm active (flashing)
= LED Day mode active
= LED Night mode active
Keys : ON/OFF = On/Off key controller
SET = Set point push button
 = Up key
 = Down key
PRG = Program key
RESET ALARM = Alarm reset key
