CDD718UB-BU CD RADIO / USB MP3 / WMA / DAB / DAB+ / DMB / Bluetooth
®
12V
Electrical Connections
n Electrical Connections
Wiring Diagram
Radio Antenna
(SMB connector)
DAB connector
(Black)
(Black)
SWRC
MIC
(Red)
(White)
AUX-L
AUX-R
VDO_CDD718UB-BU_EN.indd 10 29/04/15 12:16
