VDO CDD718UB-BU - Specifications; FM Stereo Radio

12
CDD718UB-BU CD RADIO / USB MP3 / WMA / DAB / DAB+ / DMB / Bluetooth
®
12V
Specications
General
Power supply: 12 V DC negative ground
Maximum power output: 41 W x 4 channels (4 )
Suitable speaker impedance: 4
ESP: 10 s (CD-DA)/40 s (MP3)
Dimensions(WxDxH): 178x161x50 mm
Weight: 1.33 kg
Note:
For different bit-rate MP3, ESP time are different; 40 seconds only for
the bit-rate MP3 le of the 128 Kbps.
FM Stereo Radio
Frequency range: 87.5-108.0 MHz
Usable sensitivity: < 14 dBμ
Frequency response: 50 Hz - 10 KHz
Stereo separation: ≥ 22 dB (1 KHz)
Image response ratio: ≥ 40 dB
IF response ratio: ≥ 60 dB
Signal/noise ratio: ≥ 50 dB
AM(MW) Radio
Frequency range: 522-1620 KHz
Usable sensitivity(S/N=20dB): < 35 dBμ
Disc Player
System: Disc digital audio system
Frequency response: 20 Hz - 20 KHz
Signal/noise ratio: > 72 dB (dBA)
Total harmonic distortion: Less than 1% (1 KHz)
Channel separation: > 55 dB
NORTH
AFRICA
JAPAN
531- 1602KHz
153 - 252KHz
Depending on country, the change from a standard to another (DAB, or DAB+
or FM) shall be transparent to the user.
Digital (DAB) Radio
Frequency range:
DAB Band III: 174.928MHz ~ 239.200MHz
DAB Band L:1452.960MHz ~ 1490.624MHz
Usable sensitivity (RF=-72 dBM): -95dBM
Frequency response: 20hz-20khz
Stereo separation: ≥50db
Signal/noise ratio:
≥60db
Item Min Max
Far off selectivity: 42dB 60dB
Adjacent channel rejection:
35dB 40dB
Note:
Specications and the design are subject to change without notice
due to improvements in technology.
