INSTALLATION
Connection of a repeater display unit
Make the power supply
connection for the repeater the
same as the main unit (s.p. 37).
The connection between the main
unit and the repeater is shown in
the diagram below.
4
4
Main unit
Repeater
Note that the calibration factor
C must also be set (see page
28) on the slave instrument if
such an instrument is connec-
ted.
