39
INSTALLATION / DATA
Circuit diagram legend:
S1 On/Off switch for navigation instruments
S2 On/Off switch for instrument lighting
F1 Fuse for navigation instruments (5 A)
F2 Fuse for instrument lighting (5 A)
Recommended cable section: 1.5 mm
2
Cable lengths:
Log sending unit - Indicating instrument 20 m max.
Indicating instrument - Repeater 10 m max.
Repeater 1 - Repeater 2 10 m max.
Technical data:
Measuring principle: Pulse count by Hall sensor
Supply voltage: 10.8 V to 32 V DC
Current consumption: about 100 mA at 12 V DC (without illumi-
nation), about 260 mA with illumination
Operating temperature: -10 °C to +60 °C
Type of protection: DIN 40050 - IP 65 at front
EMC protection: CE: EN 50081-1, EN 50082-1
Dimensions: Indicating instrument:
Front ring diameter 105 mm
Installation diameter 86 mm
Installation depth 56 mm (union nut)
Installation depth 90 mm (bracket)
Hull sleeve:
Installation diameter: 39 mm
Maximum hull thickness: 30 mm
Technical modifications reserved
