Viewline Level gauges
Technische Änderungen vorbehalten 12/09 Technical details subject to change 2 - 4
The reproduction, distribution and utilization of this document as well as the communication of its contents to others without express
authorization is prohibited. Offenders will be held liable for the payment of damages. All right reserved in the event of the grant of a patent,
utility model or design
.
Technical Data
Installation depth 50mm
Installation diameter 52mm
Deflection angle 90°
Operating Voltage 10 – 16 Volt
Accuracy < 3,6 angular degrees
Current consumption < 140 mA, including Warning LED
Operating temperature -30°C to +80°C; plated bezels (chrome) -30°C to +70°C
Storage temperature -40°C to +80°C for 48h; plated bezels (chrome) -40°C to +70°C
+90°C for 1h
Temperature shock Range -40°C to +85°C; plated bezels (chrome) -40°C to +70°C
Transformation time 10 seconds
Retention time 2h
Climatic test Range +25°C to +55°C
Rel. Humidity 95%
EMC in conformity with DIN_EN 61000-6-3
DIN_EN 61000-6-1
DIN_EN 61000-6-4
DIN_EN 61000-6-2
Standards EN 60945
GL, Category C, F (under preparation)
Vibration Sinus 2g; 10-500Hz; duration 16h
Noise 3g; 10-1000Hz, duration 8h
Mechanical shock continuous 25g; 6ms; 1Hz
Single shock 100g; 11ms
Free fall 1m; 3 times
Chemical resistance against - preservative agent
- preservative agent remover
- cold cleaner
- methylated spirit
- interior cleaner
- drinks containing caffeine and tannin
Nominal position NL 0 to NL 85 (DIN16257)
Protection class according to IEC 60529
Front: IP67 (in Nominal position)
Rear: IP52 (in Nominal position)
Reverse polarity protection yes, 5 minute
Over voltage protection yes, 24V for1 minute
