Viewline Tachometer without LCD
Technische Änderungen vorbehalten 12/09 Technical details subject to change 2 - 4
The reproduction, distribution and utilization of this document as well as the communication of its contents to others without express
authorization is prohibited. Offenders will be held liable for the payment of damages. All right reserved in the event of the grant of a patent,
utility model or design
.
Technical Data
Measurement Range see Table
Sensors: Hall sensor
Inductive sensor
Blocking oscillator
Ignition Terminal 1
Alternator Terminal W
Illumination amber, dimmable
Adjustment range 1, 2, 3, 4, 5, 6, 8 Pulses / Revolution (by Dip Switch)
0,5 – 399,5 Pulses / Revolution (by PC Software)
Installation depth 50mm
Installation diameter 585mm
Deflection angle 240°
Operating Voltage 8,5 – 32 Volt
Accuracy +/- 2,5% of full scale reading
Current consumption < 175 mA, including Warning LED
Operating temperature -20°C to +85°C; plated bezels (chrome) -20°C to +70°C
Storage temperature -40°C to +85°C for 48h; plated bezels (chrome) -40°C to +70°C
+90°C for 1h
Temperature shock Range -40°C to +85°C; plated bezels (chrome) -40°C to +70°C
Transformation time 10 seconds
Retention time 2h
Climatic test Range +25°C to +55°C
Rel. Humidity 80% to 100%
EMC in conformity with ISO 7637-1/2
ISO 7637-3
ESD in conformity with DIN_EN 61000-4-2
ISO/CD 10605
SAE J 551/15)
Vibration Sinus 2g; 8-500Hz; duration 16h
Noise 4,2g; 10-1000Hz, duration 8h
Mechanical shock continuous 25g; 6ms; 1Hz
Single shock 100g; 11ms
Free fall 1m; 3 times
Chemical resistance against - preservative agent
- preservative agent remover
- cold cleaner
- methylated spirit
- interior cleaner
- drinks containing caffeine and tannin
Nominal position NL 0 to NL 85 (DIN16257)
Protection class according to IEC 60529
Front: IP67 (in Nominal position)
Rear: IP52 (in Nominal position)
Reverse polarity protection yes, 1 minute
Short circuit protection yes, 1 minute
