12
5. OPERATION AS A 12 VOLT PORTABLE POWER SUPPLY
1. Lift up the cover of the unit’s 12 Volt DC accessory receptacle (See Figure 1).
2. Insert the 12 volt DC plug from the appliance into the receptacle on the unit.
3. Switch on the appliance, and operate as usual.
CAUTION: DO NOT USE THIS UNIT TO OPERATE APPLIANCES THAT
DRAW MORE THAN 5 AMPS DC
Table II shows the estimated 12 volt DC operation time when using a fully
charged system.
Table II - VECTOR® Jump-Start System as a 12 Volt DC Power Supply
Appliance Estimated Power Usage Operating Time
(Watts) (hours)
Cell phone 3 120 (talk time)
Fluorescent light 4 40
Radio, fan, depth finder 9 24
Camcorder, VCR, spotlight 15 14
Power tools, bilge pump 24 10
Car vacuum 80 2
NOTE: ALL TIMES ARE APPROXIMATE AND BASED UPON A FULLY CHARGED UNIT.
6. AREA LIGHT
The unit must be turned ON before area light is used. The area light is controlled
by an ON/OFF switch above the area light. Make sure the area light is turned OFF
when the unit is being recharged or stored. The area light is efficient and will
operate up to 200 hours on a full charge. The area light’s operating life is 100,000
hours.
7. AIR COMPRESSOR/TIRE INFLATOR
IMPORTANT:
Read Instructions Carefully To Avoid Possible Injury or Property Damage.
The built-in 12 Volt DC air compressor is the ultimate compressor for all vehicles,
trailer tires and recreational inflatables. Three different sized nozzles are supplied.
Each nozzle will clip on the end of the standard tire valve connector located at the
free end of the compressor hose. The compressor nozzles and the compressor hose
are stored in the open storage hatch on the back of the unit.
The ON/OFF button is located on the front panel of the unit. The compressor can
operate long enough to fill up to 3 average sized tires before the battery must be
recharged.
Refer to Figure 1 for locations of compressor hose, and storage hatch. Return hose
to the storage hatch after use.
7.1 WARNINGS FOR COMPRESSOR USE
The compressor is capable of inflating up to 260 pounds per square inch (PSI)
pressure. To avoid over-inflation, carefully follow instructions on articles to be
inflated. Never exceed recommended pressures. Bursting articles can cause
serious injury. Always check pressure with the pressure gauge. Never leave
compressor unattended while in use. Allow unit to cool after 15 minutes of
continuous operation.
