Doc: 70-00-0365C, V2.0, 20220523 © Vector Controls GmbH, Switzerland Page 4-22
Subject to alteration
Mounting Location
• Install the controller on an easy accessible interior wall, approx. 1.5 m above the floor in an area of average
temperature.
• Avoid direct sunlight or other heat sources, e.g. the area above radiators and heat emitting equipment.
• Avoid locations behind doors, outside walls and below or above air discharge grills and diffusers.
• Location of mounting is less critical if external temperature sensors are used.
• Ensure adequate air circulation to dissipate heat generated during operation.
• Observe local regulations.
• Do not mount in a wet or condensation prone environments.
Installation instructions
