Setting of user parameters
The TLC-BCR-T is an intelligent controller and can be adapted to fit perfectly into your application. The control
operation is defined by parameters. The parameters are set during operation by using the standard operation terminal.
The parameters may only be accessed by entering a code. There are two levels of parameters: User operation
parameters for access control settings and Expert parameters for control functions and unit setup. The codes for user
levels and expert levels are different. Only control experts should be given the control parameter code.
The parameters can be changed as follows:
1. Press UP and DOWN button simultaneously for three seconds. The display shows the software version in the
large digits and the product code in the small digits.
2. Pressing the OPTION button will indicate CODE on the small digits and 000 on the large digits.
3. The code for accessing the user parameters is 009
4. Select this using UP or DOWN buttons.
5. Press OPTION button after selecting the correct code.
6. Once logged in, the parameter is displayed immediately.
7. Select the parameters with the UP/DOWN buttons. Change a parameter by pressing the OPTION button. The
MIN and MAX symbols show up and indicate that the parameter may be modified now. Use UP or DOWN
buttons to adjust the value.
8. After you are done, press OPTION or POWER in order to return to the parameter selection level.
9. Press the POWER button again so as to leave the menu. The unit will return to normal operation if no button
is pressed for more than 5 minutes.
User Parameters
Parameter Description Setting Range Factory Setting
UP 00 Enable change of operation modes ON, OFF ON (Enabled)
UP 01 Enable change of set points ON, OFF ON (Enabled)
UP 02 Parameter not used ON, OFF ON (Enabled)
UP 03 Enable change of heating/cooling mode ON, OFF W00: ON (Enabled)
W01: OFF (Disabled)
UP 04 Enable access to Time programs ON, OFF ON (Enabled)
UP 05 State after power failure:
0 = Switched OFF, 1 = Switched ON, 2 = state before power failure
0, 1, 2 2
UP 06 Enable Economy functionality ON, OFF ON (Economy )
UP 07 Celsius or Fahrenheit, Select ON for Fahrenheit, OFF for Celsius ON, OFF OFF (Celsius)
UP 08 Calibration value of temperature sensor . This value is calibrated at
manufacturing of the thermostat. If required it is possible to shift
the temperature –10° to +10° in 0.1° K steps.
-10…10 0
UP 09 Enable frost protection ON, OFF W00 = ON
(Frost Protection)
W01 = OFF
(No Frost Protection)
UP 10 Select contents of Large LCD display in standard mode:
00 = OFF
01 = Setpoint
02 = Temperature Sensor
03 = Output State
04 = Clock
05 = Alternate Temperature Sensor
0…5 02
Temperature
UP 11 Select contents of small LCD display in standard mode
(use table of UP 10)
0…5 04 Deluxe:
show clock
01 Standard:
show setpoint
UP 12
Deluxe only
Clock display type:
OFF = Show 24hour clock
ON = Show 12hour clock (AM, PM)
ON, OFF OFF (24h)
UP 13
Deluxe only
Reset timer for override mode: Only available for deluxe version
0 = Reset of override mode is not active.
1…255 = delay in minutes to switch off device if ON/Economy
mode is activated while the unit is scheduled to be in OFF
mode
0…255 60 (Min)
