6
CONNECTING TO A PORTABLE 12 VOLT DC POWER SUPPLY,
FOR USE AWAY FROM VEHICLE
- Make sure that the unit’s COOL/WARM/OFF switch is in the OFF position.
- Insert the 12 volt DC plug on the power cord into the 12 volt DC socket on the
portable power supply and the other end of the cord into socket on cooler.
- Continue with steps 4-9, for cooler or warmer function. Observe all CAUTIONS
AND WARNINGS. Refer to page 4 for Cooling and page 5 for Warming.
Note: With a current draw of approximately 3-amps (36-watts), the unit will operate for
approximately 1.5 hours from a fully charged 12 volt DC portable power supply such as
the Vector Pocket Power™ (Model #VEC018) or Pocket Generator™ (Model #VEC018AC).
A standard 19 Ampere Hour Jumpstarter/Power Supply such as the VEC021 series -
can operate the cooler/warmer for approximately 6 hours.
CONNECTING TO AN AC (110V)/DC (12V) POWER ADAPTER
• Plug converter’s (VEC002-110V) power cord into standard 110 Volt 60 HZ outlet
• Make sure that unit’s COOL/WARM/OFF switch is in the off position
• Insert the 12 Volt DC socket of the AC/DC power adapter
and the other end into
socket on cooler.
• Continue with steps 4–9 for cooler or warmer function
OBSERVE ALL CAUTIONS AND WARNINGS.
FUSE REPLACEMENT
The power cord is fuse-protected against short-circuiting, by a 10-amp fuse
located in the tip of the 12 Volt DC power plug. If the DC socket is powered, but
the unit does not operate, then the cooler/warmer fuse may be open.
To inspect or replace the DC Power Cord Fuse
1. Unscrew the end-cap of the DC plug counter-clockwise.
2. Remove fuse, inspect it for an open element, and replace with a new 10-amp
fuse, if needed.
3. Re-attach the end-cap to the plug.
4. If new fuse opens, call Vector Customer Service department for further
instructions and possible return/replacement. This unit is not user-serviceable,
it must be returned to Vector Manufacturing for professional service or repair.
Any attempt to service by user will void warranty.
CARE AND MAINTENANCE
The Travel Cooler/Warmer is ruggedly constructed to provide years of
dependable service.
- After each use, clean the unit, inside and out, with a soft cloth and mild
soap solution.
- Do not scrape, scratch or puncture the surface of the cooler with sharp objects
or abrasives.
- Dry the unit properly and store in a cool, dry place.
- Always make sure the power cord is disconnected before storing.
- Never allow the cooler/warmer to be immersed in liquid.
Vector AC/DC
Converter
Model VEC002
