Parts Description & Replacement Parts List Cleaning the Flow Meter
21
6. Turn locking screw (21) in top block clockwise while holding flowtube (9) so as it does not turn. Torque 7.5 - 8
in-lbs.
7. Install scale (14) with desired units facing up. Align zero mark on scale (14) with zero mark on flowtube (9).
Place clear cover (20), with countersink holes facing up, align holes, and secure with four screws (18). Torque
2.5 - 3 in-lbs.
8. Install white plastic shield (17) on back over connectors (13).
9. Remount flowmeter with two mounting nuts (4).
Stops are not interchangeable. The top stop is larger to accommodate the tapered tube ID.
