Veeder-Root TLS-300I/C Installation Manual

Appendix C: Device DIP Switch Settings Transmitter/Receiver/Repeater DIP Switch Settings
C-4
Figure C-5. Mode Settings - S2:DIP switches 1-4
c-5.eps
RPTR RCVR
No Change (Idle) Fall (Dispense) Rise (Delivery) No Change (Idle) Change (Leak)
1 2 3 4 Read/Tx Read/Tx Read/Tx Poll/Tx Poll/Tx ID VR Bus Address
OFF OFF OFF OFF 6/120 6/30 6/6 6/120 6/6 0 0
OFF OFF OFF ON 6/120 6/6 6/6 6/120 6/6 1 0
OFF OFF ON OFF 120/120 120/120 120/120 120/120 120/6 2 0
OFF OFF ON ON 600/600 600/600 600/600 600/600 600/6 3 0
OFF ON OFF OFF 3600/3600 3600/3600 3600/3600 3600/3600 3600/6 4 1
OFF ON OFF ON Do Not Set Do Not Set Do Not Set Do Not Set Do Not Set 5 1
OFF ON ON OFF Do Not Set Do Not Set Do Not Set Do Not Set Do Not Set 6 1
OFF ON ON ON Do Not Set Do Not Set Do Not Set Do Not Set Do Not Set 7 1
ON OFF OFF OFF Do Not Set Do Not Set Do Not Set Do Not Set Do Not Set 8 2
ON OFF OFF ON Do Not Set Do Not Set Do Not Set Do Not Set Do Not Set 9 2
ON OFF ON OFF Do Not Set Do Not Set Do Not Set Do Not Set Do Not Set 10 2
ON OFF ON ON Do Not Set Do Not Set Do Not Set Do Not Set Do Not Set 11 2
ON ON OFF OFF Do Not Set Do Not Set Do Not Set Do Not Set Do Not Set 12 3
ON ON OFF ON Do Not Set Do Not Set Do Not Set Do Not Set Do Not Set 13 3
ON ON ON OFF Do Not Set Do Not Set Do Not Set Do Not Set Do Not Set 14 3
ON ON ON ON Do Not Set Do Not Set Do Not Set Do Not Set Do Not Set 15 3
RPTR RCVR
No Change (Idle) Fall (Dispense) Rise (Delivery) No Change (Idle) Change (Leak)
1 2 3 4 Read/Tx Read/Tx Read/Tx Poll/Tx Poll/Tx ID VR Bus Address
OFF OFF OFF OFF 6/120 6/30 6/6 6/120 6/6 0 0
OFF OFF OFF ON 6/120 6/6 6/6 6/120 6/6 1 0
OFF OFF ON OFF 120/120 120/120 120/120 120/120 120/6 2 0
OFF OFF ON ON 600/600 600/600 600/600 600/600 600/6 3 0
OFF ON OFF OFF 3600/3600 3600/3600 3600/3600 3600/3600 3600/6 4 1
OFF ON OFF ON 6/120 6/30 6/6 6/120 6/6 5 1
OFF ON ON OFF 6/120 6/30 6/6 6/120 6/6 6 1
OFF ON ON ON 6/120 6/30 6/6 6/120 6/6 7 1
ON OFF OFF OFF 6/120 6/30 6/6 6/120 6/6 0 2
ON OFF OFF ON
ON OFF ON OFF
ON OFF ON ON
ON ON OFF OFF
ON ON OFF ON
ON ON ON OFF
ON ON ON ON
Reserved for future use
Reserved for future use
Reserved for future use
Mag Sump XMTR: Read/Transmit Interval
Mag Probe XMTR: Read/Transmit Interval
SystemID: Green Blinks = Software Version; Red Blinks- 1: 900MHz, 2:869MHz
RF Status: Green - On\Off with Radio power; Red: On during host to radio communication
Version 3 (Australia/Italy)
Version 1 (NA/EMEA)
S2: SW1~4
Mag Probe XMTR: Read/Transmit Interval
Mag Sump XMTR: Read/Transmit Interval
Reserved for future use
S2: SW1~4
Reserved for future use
*
*
*
* in seconds
*
