1
Introduction
This manual assumes that you are installing the console in a new site (before pavement is put down and with no
wiring runs in place). Among the topics covered are:
• Site layout considerations.
• Installing the console and connecting wiring from the AC power panel.
• Probe installation procedures.
• Sensor installation procedures.
• Installing wiring conduit between the console and the probes and sensors.
• Probe and sensor field junction box wiring diagrams.
• Attaching sensor wiring to the console.
Related Documents
DOCUMENTS REQUIRED TO INSTALL EQUIPMENT
This equipment must be installed according to the applicable installation document:
Safety Precautions
The following safety symbols may be used throughout this manual to alert you to important safety hazards and
precautions.
Equipment
ATEX
Descriptive System
IECEx
Descriptive System
UL/cUL
Control Drawing
Document No. Document No. Document No.
Associated Apparatus
TLS-450/TLS-450PLUS 331940-006 331940-106 331940-008
Intrinsically Safe Apparatus for Wireless Applications
Tank Gauge Accessories 331940-005 331940-105 331940-012
EXPLOSIVE
Fuels and their vapors are extremely
explosive if ignited.
FLAMMABLE
Fuels and their vapors are extremely flammable.
ELECTRICITY
High voltage exists in, and is supplied to,
the device. A potential shock hazard
exists.
TURN ELECTICAL POWER OFF
Live power to a device creates a potential shock
hazard. Turn Off electrical power to the device and
associated accessories when servicing the unit.
WARNING
Heed the adjacent instructions to avoid
damage to equipment, property, environ-
ment or personal injury.
READ ALL RELATED MANUALS
Knowledge of all related procedures before you
begin work is important. Read and understand all
manuals thoroughly. If you do not understand a pro-
cedure, ask someone who does.
