Veeder-Root TLS-450/8600 Install, Setup, & Operation Manual

Operation Viewing PMC Reports Via RS-232 Connection
Table 3. Serial Commands for PMC Diagnostic Reports
Report Type Serial Command (PC to Console)*
Vapor Processor Status Report
(See example Figure 13)
<SOH>IV8200
Vapor Processor Runtime Diagnostic Report
(See example Figure 14)
<SOH>IV8000
Percent Hydrocarbon Diagnostic Report (See
example Figure 15)
<SOH>IV8100
*<SOH> = Control A. For more information on TLS console serial commands, refer to
the V-R Serial Interface Manual.
Section 16
Pressure Management Control
16-15
