IMPORTANT *****
ENSURE STAND TROLLEYS ARE ONLY USED ON FLAT, HARD LEVEL
GROUND
The wheels will not work on soft areas.
Once filled with soil the Vegepods are very heavy. So please ensure the wheels are
locked and secure.
1. Select the 2 ‘angle cross braces with holes’(
that have 2 holes in the middle of them). Lay
them on the ground with the side with the
middle holes flat on ground.
2. Place ‘cross brace tubes’ so the holes line up.
Select 4 mid-size bolts with rounded head.
Feed bolt upwards so it sticks out the top of the
cross brace tube, then screw nut on till finger
tight.
3. Select the 4 corner braces. Attach long angle
cross braces to the inside of the corner braces using
SHORT bolts. Make sure the longer side of the corner
brace is pointing up (you are making this upside down
for now) – Just finger
tight for now.
To Next Page
