SI21 Solar Pump VFD Manual
7
SI21-D5-5R5G-A
4
W1
W
W2
H2
H1
D
D1
H
Installation hole
diameter
7.5kW-22kW Installation Dimension Drawing
Model
Dimension (mm)
Positive
mounting
dimensions
(mm)
Side mounting
dimensions
(mm)
Mo
unt
ing
hol
e
dia
met
er
W
H
H1
D
D1
W
1
W2
H2
W
3
H3
H4
SI21-D5-7R5G-A
130
320
286
161
158
105
12.5
302
一
一
一
M5
SI21-D5-011G-A
SI21-D5-015G-A
170
342.5
303.5
183
180
145
12.5
326.5
一
一
一
M6
SI21-D5-018G-A
SI21-D5-022G-A
