veito FLOW S - Technical Specifications

Electrical Connection
1/N/PE 220 - 240 V
50 / 60 Hz
Technical Specifications
MODEL FLOW FLOW S
Power 7500 W 9000 W
1/N/PE 220 - 240 V
50 / 60 Hz
Minimum Cable
Cross-Section
4 mm
2
6 mm
2
Fuse Current 32 A 40 A
Water Connection G 1/2 G 1/2
Heating System
Bare Wire
Bare Wire
Maximum hot water
capacity at Δt = 25 °C
4 l/dk
4,5 l/dk
Operating Pressure 0,05 MPa ( 0,5 bar ) 0,05 MPa ( 0,5 bar )
Rated Pressure 1 MPa ( 10 bar ) 1 MPa ( 10 bar )
Specific electrical
resistance of water
used at 15 ° C
≤ 1300 Ωcm ≤ 1300 Ωcm
Net Weight 2,5 kg 2,5 kg
Protection Class/Type 1 / IP24 1 / IP24
-38-
EN
