10. MOUNT THE LEDs, BEND THE LEADS CAREFULLY
(Check the polarity)
PCB
SOLDER
SIDE
LED
q LD1: green (5)
LD...
COLOR = 2...5
CATHODE
q LD2: green (5)
q LD3: green (5)
q LD4: green (5)
q LD5: green (5)
q LD6: green (5)
q LD7: green (5)
q LD8: yellow (4)
q LD9: yellow (4)
q LD10: red (2)
