DVM890L GB 10
4.6 Resistance
Range Resolution Accuracy
200Ω 0.1Ω ± 0.8% of rdg ± 3 digits
2kΩ 1Ω
20kΩ 10Ω ± 0.8% of rdg ± 1 digits
200kΩ 100Ω
2MΩ 1kΩ
20MΩ 10kΩ ± 1% of rdg ± 2 digits
200MΩ 100kΩ ± 5% of rdg ± 10 digits
For the 200MΩ range, short the two test leads first. If the displayed value comprises 10 digits, these
10 digits should be subtracted from the measurement result.
4.7 Capacitance
Range Resolution Accuracy
2000pF 1pF
20nF 10pF
200nF 100pF
± 2.5% of rdg ± 5 digits
2µF 1nF
20µF 10nF
4.8 Transistor hFE test
Range Description Test condition
hFE Display shows approx. hFE-value (0-
1000) of the transistor under test (ALL
TYPES)
Base Current approx. 10µA,
Vce approx. 2.8V
4.9 Temperature
Range Temperature range Accuracy Resolution
- 50°C - 400°C
± 0.75% of rdg ± 3°C
1°C
T 400°C - 1000°C
± 1.5% of rdg ± 15°C
1°C
0°C - 40°C
± 2°C
1°C
Using K type thermocouple probe
Built-in temperature sensor
