Velleman DVM1100 User Manual

DVM1100 VELLEMAN
-
11
-
Resistance
Function Range Resolution Accuracy
400.0Ω 0.1Ω ± 0.5% + 3 digits
4.000kΩ 1Ω
40.00kΩ 10Ω
400.0kΩ 100Ω
4.000kΩ 1kΩ
± 0.5% + 2 digits Resistance Ω
40.00MΩ 10kΩ ± 1.5% + 3 digits
Overload Protection: 1,000VDC or 1,000VAC RMS
Diode
Function Range Resolution Accuracy
Diode test 1V 0.001V 1.0% uncertainty
Forward DC Current: ± 1mA
Reverse DC Voltage: ± 1.5V
Overload Protection: 1,000VDC or 1,000 VAC RMS
Continuity Check
Function Range Resolution Test Condition
400Ω 0.1Ω
Open circuit voltage
approx. 0.5V
Continuity beeper: ≤ 75Ω
Overload Protection: 1,000VDC or 1,000VAC RMS
Temperature
Function Range Resolution Accuracy
-55C°~0°C ± 9.0% + 2°C
1°C~400°C
0.1°C
± 2.0% + 1°C
Celsius
1
401°C~1,000°C 1°C ± 2.0%
1
Temperature specifications do not include thermocouple errors
Overload Protection: 1,000VDC or 1,000VAC RMS
Capacitance
Function Range Resolution Accuracy
50nF 10pF
< 10nF: ± 5.0% - 50 digits
± 3.0% + 10 digits
500nF 100pF
5µF 1nF
50µF 10nF
Capacitance
100µF 100nF
± 3.0% + 5 digits
Overload Protection: 1,000VDC or 1,000VDC
