DVM2000 VELLEMAN
13
50V 1mV
± (0.5% + 40)
± (1% + 40)
± (2.5% + 40)
500VV 10mV unspecified
1000V 0.1V unspecified unspecified
Above accuracies guaranteed within 10%~100% of the full range.
DC Voltage
Range Resolution Accuracy
50mV 0.001mV ± (0.03% + 10)
500mV 0.01mV
± (0.03% + 6)
5V 0.1mV
50V 1mV
500V 10mV
1000V 0.1V
Above accuracies guaranteed within the full range.
AC Current/DC + AC Current
Range Resolution
Accuracy Voltage Drop
40Hz~1kHz 1kHz~10kHz 10kHz~20kHz
500µA 0.01µA ± (0.75% + 20) ± (1% + 20) ± (2% + 20)
102µV/µA
5000µA 0.1µA ± (0.75% + 10) ± (1% + 10) ± (2% + 10)
50mA 1µA ± (0.75% + 20) ± (1% + 20) ± (2% + 20)
1.5mA/mA
500mA 10µA ± (0.75% + 10) ± (1% + 10) ± (2% + 10)
5A 0.1mA ± (0.75% + 20) ± (1.5% + 20) ± (5% + 20)
30mV/A
10A 1mA ± (1.0% + 10) ± (1.5% + 10) unspecified
Above accuracies guaranteed within 10%~100% of the full range.
