Velleman DVM9915 - Voltage Measurement; Current Measurement

DVM9915
V. 03 – 29/11/2017 12 ©Velleman nv
9.9 DUTY CYCLE
Do not conduct duty cycle measurements on live
circuits
range
accuracy
0.1-99.9 %
± (2.0 % rdg + 2 digits)
Frequency: < 10 kHz
Sensitivity: sine wave 0.6 V rms
Overload protection: 600 V DC or AC rms
9.10 TEMPERATURE
range
accuracy
resolution
°C
-50 to 150 °C
± (3 °C + 1 digit)
1 °C
150 to 800 °C
± (3 % + 1 digit)
NiCr-NiSi sensor
Overload protection: 0.5 A/600 V fuse
10. Voltage Measurement
Do not measure circuits that may contain voltages > 600 V
Use extreme caution when measuring voltages higher than 60 VDC
or 30 VAC rms.
Always place your fingers behind the protective edges of the test
probes while measuring!
1. Connect the red test lead to the “VmA” jack and the black lead to the
“COM” jack.
2. Set the rotary switch in the desired V position.
3. Press “SELECT” and choose the “AC” or “DC” measurement mode.
4. Connect the test leads to the source being measured.
5. Read the voltage value on the LCD display.
6. In “AC” measurement mode, press “Hz%” to measure frequency or
duty cycle.
11. Current Measurement
Do not measure circuits that may contain voltages > 600 V
Use extreme caution when measuring voltages higher than 60 VDC
or 30 VAC rms.
Always place your fingers behind the protective edges of the test
probes while measuring!
