The K2579 is a basic timer with relay output for time intervals of up to 15 minutes.
Set the desired delay with the trimmer.
The maximum delay can easily be lengthened and the timer can be stopped and restarted at any time.
Features
Start / stop push buttons included.
LED status indicator.
Timing adjustable from a few seconds to 15 minutes, extendable to 60 minutes.
Relay output with switchover contact.
Specifications :
Power supply : 12VDC regulated.
Typical idle current : 20mA.
Typical active current : 55mA.
Relay output : 2A/240V max.
Dimensions : 38x69mm / 1.5”x2.7”.
Features & Specifications
