Velleman PCS500 - System Requirements and Technical Data; Minimum System Requirements; Technical Specifications

PCS500 / PCS100 / K8031
5
Minimum system requirements
• IBM compatible PC
• Windows 95, 98, ME, (Win2000 or NT possible)
• SVGA display card (min. 800x600)
• Mouse
• Free printer port LPT1, LPT2 or LPT3
• CD Rom player
Options
• Insulated measurement probe x1 / x10: PROBE60S
• Soft carry case: GIP
Technical data
PCS500 Oscilloscope
• Time base: 20ns to 100ms per division
• Trigger source: CH1, CH2, EXT or free run
• Trigger level: adjustable in whole screen
• Input sensitivity: 5mV (10mV for PCS100 / K8031) to 15V/division
• Record length: 4096 samples / channel
• Sampling frequency: Real time* 1.25 kHz to 50 MHz
• Sampling frequency: Repetitive*: 1 GHz (Equivalent Sampling Rate)
PCS100 / K8031 Oscilloscopes
• Time base: 0.1us to 100ms per division
• Trigger source: CH1 or free run
• Trigger level: adjustable per ½ division
• Input sensitivity: 10mV to 3V per division
• Record length: 4079 samples
• Sampling frequency: Real time* 800Hz to 32MHz
PCS500 / PCS100 / K8031 general data
• Trigger edge: rising or falling
• Step markers for voltage, time and frequency
• Interpolation: linear or smoothed
• Vertical resolution: 8 bit
• Auto setup function
• True RMS readout (only AC component)
(*) Real-time Sampling:
A sampling mode in which the picture is build by collecting as many samples
as it can as the signal occurs.
(*) Equivalent Sampling rate:
A sampling mode in which the picture is builds using repetitive signals by
capturing information from each repetition.
