Vello BG-C9 - Mounting Screw

4. To prevent loss, place the
camera battery chamber
cover into the BG-C9
battery chamber holder.
as indicated above. Swing
the battery chamber cover
shut so that it locks into
place
5. Remove the protective
cap and connect the BG-
C9 grip to the camera,
while aligning the grip’s
mounting screw with the
camera’s tripod socket.
6. Rotate the attachment
wheel in the direction
shown by the arrow until
it is firmly tightened.
1
2
3
When removing the grip,
turn the camera power off,
remove batteries, and replace
protective contact cap.
