Vello shutterboss II User Manual

9
You can use your transmitter as a wired
remote. With your camera and transmitter
both OFF, connect the shutter release cable’s
sub-mini plug end to the jack at the front of
the transmitter and the other end to your
camera’s shutter release jack. Power up your
camera.
WIRED SETUP
Look for this symbol.
Many camera manufacturers
use it to indicate the jack for
connecting remote devices.

Vello shutterboss II Specifications

General

Supported Cameras	(See enclosed insert)
Exposure Range	0s to 99hr 59min 59s in one-second increments
Number of Shots	1-999 or ∞
Frequency	99 selectable channels over FSK 2.4 GHz
Range	250 feet (80 meters)
Timer Control: Delay	0s to 99hr 59min 59s in one-second increments
Interval	1s to 99hr 59min 59s in one-second increments
Operating Temperature	−4° to +122°F (−20° to +50°C)

Weight and Dimensions

Dimensions (Transmitter)	5.9" × 2" × 1" (149 × 50 × 24 mm)
Dimensions (Receiver)	2.5" × 1.5" × 1.2" (63 × 38 × 31 mm)
