VELTIUM LITE Zero - METER SET INSTALLATION

21
INSTALLATION
MANUAL
INSTALLATION
4. Run a 1.5 two-cable wire between the CURVE device and the charger.
5. Strip 8 mm from each wire of the cable and connect it to the terminals of the
CURVE device.
8 mm
6. Strip 8 mm from each wire of the cable and connect the CURVE device to the
charger in the pins indicated.
LITE Zero
LITE Uno
