18
INSTALLATION
MANUAL
5. Mount the charger onto the STAND element. Follow points 8 to 12 of the charger
assembly instructions.
The fasteners to be used in this case must be those provided with the
STAND element, and not those supplied with the charger.
Given that in this case the power supply does not come through the side
of the charger, this access must be covered using the blind grommet
provided with the charger.
6. Replace the top part of the STAND element.
3- INSTALLATION
