26
INSTALLATION
MANUAL
4- TECHNICAL SPECIFICATIONS
Mechanical
Material Flame retardant PC/ASA (V0)
Anchor type
• Wall
• Floor with STAND accessory
Height (mm) 365
Width (mm) 220
Depth (mm) 105
Weight (including 5m/7m charging cable) 3.75 kg/4.35 kg 4.35 kg/ 4.95 kg
IP Grade IP54
IK Grade IK10
Plug holder (tethered cable model) Integrated to the unit
Cable length (tethered cable model)
• 5 meters
• 7 meters
Power supply connection Accessible from the exterior (no need to open the charger during installation)
Cable gauge 16 mm
2
Colour
• White
• Black
• Blue
• Orange
Environmental
Suitable for outdoor use Yes
Operating temperature -25 to 40°C
Storage temperature -25 to 60°C
Communications
Bluetooth BLE 4.2
Wi-Fi No 802.11 b/g/n
Ethernet No 2 x RJ45
LITE Zero LITE Uno LITE Kubo
