VentilClima VCE10 - Page 27

TECHNICAL MANUAL
VERSIONE 7 - Vertical recessed models (frontal air discharge)
VCE 17-97
C
D
L
25
25
147
122 G
H
A
B
E
F
M
X
N
Y
Ø 20
147
200
S
S
L
L
H
S
L
S
C
D
L
25
25
167
72
278
153
328
175
389
120
112
62
36
141
Ø20
167
H
231
S
LEFT
VERSION
H
167
Ø 20
231
S
62
111
7563
120
389
215
308
RIGHT
VERSION
VCE 107-127
Dimensions Standard coil Auxiliary coilDistance
between slots
MOD. CODE H L S C D G N Y A B M X E F
VCE17 A0015090017 460 420 220 370 395 233 39 109 274 137 103 53 337 67
VCE27 A0015090027 460 620 220 570 595 233 39 109 274 137 103 53 337 67
VCE37 A0015090037 460 820 220 770 795 233 39 109 274 137 103 53 337 67
VCE47 A0015090047 460 820 220 770 795 233 39 109 274 137 103 53 337 67
VCE57 A0015090057 460 1.020 220 970 995 233 39 109 274 137 103 53 337 67
VCE67 A0015090067 460 1.020 220 970 995 233 39 109 274 137 103 53 337 67
VCE77 A0015090077 565 1.020 220 970 995 253 41 107 268 253 101 52 374 124
VCE87 A0015090087 565 1.220 220 1.170 1.195 253 41 107 268 253 101 52 374 124
VCE97 A0015090097 565 1.220 220 1.170 1.195 253 41 107 268 253 101 52 374 124
VCE107 A0015090107 585 1.385 252 1.335 1.362 - - - - - - - - -
VCE117 A0015090117 585 1.685 252 1.635 1.662 - - - - - - - - -
VCE127 A0015090127 585 1.685 252 1.635 1.662 - - - - - - - - -
range
27
