VentilClima VCE20 - Page 33

TECHNICAL MANUAL
FRESH AIR LOUVER
129
115
14
195
LI
30
84
LU
LT
For VERTICAL
VERSION
VCE18 A0055470021 255 105 105 200
VCE28 A0055470022 455 105 105 200
VCE38 A0055470023 655 105 105 200
VCE48 A0055470023 655 105 105 200
VCE58 A0055470024 855 105 105 200
VCE68 A0055470024 855 105 105 200
VCE78 A0055470024 855 105 105 200
VCE88 A0055470025 1.055 105 105 200
VCE98 A0055470025 1.055 105 105 200
VCE108 A0055470026 1.180 140 140 230
VCE118 A0055470027 1.480 140 140 230
VCE128 A0055470027 1.480 140 140 230
MOD. CODE L A B C
mm mm mm mm
C
14
B
L
A
130
For HORIZONTAL
VERSION
VCE11 A0055470028 253 367 397
VCE21 A0055470029 453 567 597
VCE31 A0055470030 653 767 797
VCE41 A0055470030 653 767 797
VCE51 A0055470031 853 967 997
VCE61 A0055470031 853 967 997
VCE71 A0055470031 853 967 997
VCE81 A0055470032 1.053 1.167 1.197
VCE91 A0055470032 1.053 1.167 1.197
VCE101 A0055470033 1.208 1.322 1.352
VCE111 A0055470034 1.408 1.522 1.552
VCE121 A0055470034 1.408 1.522 1.552
MOD. CODE LU LI LT
mm mm mm
VCE12/7 A0055470039 255 313 397
VCE22/7 A0055470040 455 513 597
VCE32/7 A0055470041 655 713 797
VCE42/7 A0055470041 655 713 797
VCE52/7 A0055470042 855 913 997
VCE62/7 A0055470042 855 913 997
VCE72/7 A0055470042 855 913 997
VCE82/7 A0055470043 1.055 1.113 1.197
VCE92/7 A0055470043 1.055 1.113 1.197
VCE102/7 A0055470044 1.210 1.268 1.352
VCE112/7 A0055470045 1.410 1.468 1.552
VCE122/7 A0055470045 1.410 1.468 1.552
MOD. CODE LU LI LT
mm mm mm
For RECESSED
VERTICAL VERSION
LU
30
28
LI
149
134
15
195
LT
LT
195
LU
163
LI
For RECESSED
HORIZONTAL VERSION
VCE13 A0055470046 255 313 397
VCE23 A0055470047 455 513 597
VCE33 A0055470048 655 713 797
VCE43 A0055470048 655 713 797
VCE53 A0055470049 855 913 997
VCE63 A0055470049 855 913 997
VCE73 A0055470049 855 913 997
VCE83 A0055470050 1.055 1.113 1.197
VCE93 A0055470050 1.055 1.113 1.197
VCE103 A0055470051 1.210 1.268 1.352
VCE113 A0055470052 1.410 1.468 1.552
VCE123 A0055470052 1.410 1.468 1.552
MOD. CODE LU LI LT
mm mm mm
VCEx8
VCEx1
VCEx7
VCEx2
VCEx3
range
33
